Model
BYG-DBS02

Review

Description

characteristic

 Can be integrated with printer and labeler;

 Integrated with servo Ethernet communication; - filling of various products In-bag solution; with optional heat transfer or labeler

Performance:

The electromagnet is used to press the sealing to ensure the sealing pressure is stable. good sealing quality.                                                                                             High-pressure box length detection sensor, automatic detection of bag length and sealing position accuracy 1mm.

User Benefits:

Compact design is ideal for low- to mid-volume packaging operations                        Locking turntable and Auto Thread feature provide easy bag access and changeover

   Open loading area and controlled seal bar safety.

   Automatic or manual operation modes       for  optimum flexibility

 maximize loading flexibility and operator
Parameter
Capacity
20-25bags/minute
Apply bag size
L105mm -650mm                 W30mm -245mm
DBS03 Width Max 350mm
Bag thickness
single layer 0.04-0.1mm
Application
Clear  Color PE Poly Bag/ Mailer Bag
Power Supply
Single Phase 220V/110V 50/60HZ
Dimension(L*W*H)
L700*W650*H620
Weight
65kg
Certification
CE
application
The BYG-DBS Series is simple to operate, with a user-friendly display that enables easy access to operating parameters, job set-up, job storage, and on-board system diagnostics. The unique, locking turntable combines with the AutoThread feature to provide ergonomic handling and changeover of Autobag bags-on-a-roll. Bags are automatically indexed, loaded by hand, then sealed using the Push-to-Seal function, a standard footswitch, or via automatic cycle control.
